Teradek RT Single-Axis Wireless Follow Focus Kit
Kit Includes
- (1) CTRL.1 - Single Axis Wireless Controller With Lens Mapping (Hand Unit)
- (1) Teradek Latitude MDR-M Receiver With Captive 1/4"-20 Screw
- (1) Teradek MOTR.X
- (1) Teradek 19mm Rod Clamp With 15mm Insert
- (3) Blank Focus Ring - Type B
- (1) Pre-Marked Iris Ring - T1 - T32
- (1) Pre-Marked Focus Ring - 10" Minimum
- (1) Pre-Marked Focus Ring - 20" Minimum
- (1) Pre-Marked Focus Ring - 3.6' Minimum
- (1) Pre-Marked Focus Ring - 6' Minimum
- (1) Pre-Marked Focus Ring - 101 Minimum
- (1) Zipper Pouch
- (1) 1' - D-Tap To Angled 2-Pin Lemo (Latitude Power Cable)
- (1) 8" - ST To ST Motor Cable
- (1) 8" - Micro USB To 5 Pin Cable
- (1) 18" - Mini USB To USB Cable
- (1) 8" - 2M Wired Mode Cable
- (1) 15mm/19mm Rod Clamp With 1/4"-20 Screw Mount
- (3) LP-E6 Battery
- (1) LP-E6 Battery Charger
- (1) Controller Neck Strap
- (1) Hard Case
Rates
$125.00 Day/Weekend Rate
$375.00 Week Rate
$1,125.00 Month Rate
Specs
Single-Axis Wireless Lens Controller
- Compatibility:
Teradek RT motors and receivers
- Function:
Focus, iris, or zoom
- Wireless Range:
5000' +/-
- Display:
OLED
- Control Port:
5-pin motor control
- Dimensions:
N/A
- Weight:
N/A
Latitude MDR-M Receiver
- Interface – Connectors:
1 x Power-In: 2-pin LEMO 0B, 7-17 VDC
2 x Accessory In: 5-pin LEMO 0B
1 x Motor: 4-pin LEMO 0B
(Use separately available breakout cable to control 2 x motors)
1 x Control (Camera): 4-pin LEMO 00B
(RS-232 for RED control, serial control for LANC, programmable line driver for select cameras)
1 x USB: Mini-USB (firmware updates)
- WiFi Connectivity:
1 x 2.4 GHz WiFi module
1 x 2.4 GHz RT FHSS wireless module
- Wireless Range:
RT FHSS:
Line-of-sight: Up to 4921' (in USA/FCC mode)
Indoors: Up to 492'
WiFi: Outdoors: Up to 328'
- Operating Temperature Range:
-4 to 122°F
- Storage Temperature Range:
-40 to 185°F
- Dimensions:
3.9 x 1.9 x 0.9"
- Weight:
3.7 oz
Lens Motor
- Material of Construction:
Aluminum
- Connectors:
Input: 1 x 0B.4 (Daisy-Chainable)
Output: 1 x 0B.4 (Daisy-Chainable)
- Gear Pitch:
0.8 MOD
- Maximum Speed:
6.2 rps
- Torque:
3 Nm Peak, 2 Nm Continuous
- Rod Compatibility:
15 and 19 mm
- Operating Voltage:
7 to 17 V
- Operating Temperature:
-4 to 122°F
- Dimensions:
N/A
- Weight:
N/A
