$175.00 Day/Weekend Rate
$525.00 Week Rate
$1,57500 Month Rate

We offer a price match guarantee—if you find a lower advertised rate for the same equipment from another Chicago rental house, we'll match it, no questions asked.

For custom rental periods or special requirements, contact our team at rentals@cameraambassador.com to discuss tailored pricing.

IP Rating:

• IP 54

Panel Type:

• IPS LCD

Diagonal Size:

• 7.02"

Resolution:

• 1920x1200

Max Brightness:

• 2300nits

Contrast:

• 1000:1

Color Depth:

• 10-bit Processing (8-bit panel)

Backlight Type:

• LED Edgelit

Refresh Rate:

• Synchronizes with input from 48Hz to 60Hz

3G-SDI Input Types:

• YCC 4:2:2 @ 10-bits: 1080p60, 1080p59.94, 1080p50, 1080i120, 1080i119.88, 1080i102

6G-SDI Input Types:

• YCC 4:2:2 @ 10 bits: DCI-4Kp30, DCI-4Kp29.97, DCI-4Kp25, DCI-4Kp24, DCI-4Kp23.98, 2160p30, 2160p29.97, 2160p24, 2160p23.98 YCC 4:4:4, YCC+A 4:4:4:4, RGB, RGB+A @ 10 bits: DCI-2Kp60, DCI-2Kp59.94, DCI-2Kp50, DCI-2Kp48, DCI-2Kp47.95, 1080p60, 1080p59.94, 1080p50, 1080p48, 1080p47.95 YCC 4:4:4, YCC+A 4:2:2:4, RGB @ 12 bits: DCI-2Kp60, DCI-2Kp59.94, DCI-2Kp50, DCI-2Kp48, DCI-2Kp47.95, 1080p60, 1080p59.94, 1080p50, 1080p48, 1080p47.95

HD-SDI Input Types:

• YCC 4:2:2 @ 10-bits: 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080i60, 1080i59.94, 1080i50, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.100

SD-SDI Input Types:

• YCC 4:2:2 @ 10-bits: 480i59.94, 576i52

HDMI Input Types:

• YCC 4:2:2 @ 12 bits, 8/10/12/16 bit color in RGB & YCC 4:4:4: 3840x2160 30p, 1080p60, 1080p59.94, 1080p50, 1080p30, 1080p29.97 1080p25, 1080p24, 1080p23.98, 720p120, 720p119.88, 720p100, 720p60, 720p59.94 , 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98, 480p240, 480p239.76, 480p120, 480p119.88, 480p60, 480p59.94, 576p200, 576p100, 576p50, 480i240, 480i239.76, 480i120, 480i119.88, 480i60, 480i59.94, 576i200, 576i100, 576i52

3G-SDI Output Types:

• YCC 4:2:2 @ 10-bits: 1080p60, 1080p59.94, 1080p50, 1080i120, 1080i119.88, 1080i102

HD-SDI Output Types:

• YCC 4:2:2 @ 10-bits: 1080p30, 1080p29.97, 1080p25, 1080p24, 1080p23.98, 1080psf30, 1080psf29.97, 1080psf25, 1080psf24, 1080psf23.98, 1080i60, 1080i59.94, 1080i50, 720p60, 720p59.94, 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.100

SD-SDI Output Types:

• YCC 4:2:2 @ 10-bits: 480i59.94, 576i52

HDMI Output Types:

• YCC 4:2:2 @ 12 bits, 8 bit color in RGB & YCC 4:4:4: 2160p30, 2160p29.97, 2160p25, 2160p24, 2160p23.98, 1080p120, 1080p119.88, 1080p100, 1080i120, 1080i119.88, 1080i100, 1080i60, 1080i59.94, 1080i50, 720p240, 720p239.76, 720p200 YCC 4:2:2 @ 12 bits, 8/10/12/16 bit color in RGB & YCC 4:4:4: 1080p60, 1080p59.94, 1080p50, 1080p30, 1080p29.97 1080p25, 1080p24, 1080p23.98, 720p120, 720p119.88, 720p100, 720p60, 720p59.94 , 720p50, 720p30, 720p29.97, 720p25, 720p24, 720p23.98, 480p240, 480p239.76, 480p120, 480p119.88, 480p60, 480p59.94, 576p200, 576p100, 576p50, 480i240, 480i239.76, 480i120, 480i119.88, 480i60, 480i59.94, 576i200, 576i100, 576i51

Audio Output Types:

• HDMI & SDI - Incoming Audio Stream is sent downstream via HDMI or SDI connection

SDI:

• 1x BNC 6G input and 1x BNC 6G input/output

HDMI:

• 1 input and 1 output: HDMI Type-A Receptacles (full size)

Audio:

• 1x 3.5mm 3-pin Stereo Headphone Jack

Ethernet:

• RJ45

Connector:

• 2-Pin Locking Connector

Voltage:

• DC in - 10V minimum to 34V maximum, Battery terminals - 10V minimum to 34V max

Power Supply:

• Recommend DC 12~15V at ~2.5 amp or greater

Battery Plate Type:

• Gold Mount

Overload Protection:

• DC input: Reverse polarity

Pixel Zoom:

•  1.1-2.0x & 2.0-8.0x via swipe up/down. Infinitely adjustable via pinch & zoom

Frame Guides:

• Preset Aspect Ratios & Customizable

DSLR Scale:

• Canon 5DMkii & Canon 7D

Custom Scale:

• Yes (Underscan Only)

Anamorphic De-Squeeze:

• 0.75x, 1.33x, 1.5x, 1.66x, 2.0x, 2.5x

Image Rotate:

• Automatic or Manual Control

Image Flip:

• Automatic or Manual Control

Cross Conversion:

• Yes: HDMI → SDI & SDI → HDMI

Focus Assist:

• User Adjustable Color Style and Intensity

Peaking:

• User Adjustable Intensity

False Color:

• Rainbow, Arri Style, Custom with up to 10 nodes

Zebra:

• Dual - User Configurable

Waveform:

• Luma & RGB Style, Fully User Customizable w/ Region of Interest Highlighting

Vectorscope:

• Yes

RGB Parade:

• Fully User Customizable

Histogram:

• Luma & RGB Style

Image Capture:

• Yes

LUTS:

• 33pt User LUT instead of 17pt - 33pt Cal LUT instead of 17pt - LUT tool continues to work after removable media containing the LUT has been removed

Custom LUTS:

• Loadable as Looks on Pages or as System Wide Color Calibration via the settings menu - LUT Downstream: Available on SDI or HDMI Out. Applied on Output Preview Page - LUT Import: via SD Card or USB Storage Device

Color Pipe:

• Unique Calibrations may be saved to each Color Pipe - Accurate color processing

Overlay:

• With Opacity Slider and Blink Setting

Audio Meters:

• HDMI & SDI up to 8 channel

Multi-View:

• 2 camera feeds simultaneously

Dimensions:

• 1.36” x 5.12” x 8.23”

Weight:

• 32 oz

• Daylight-viewable 7" touchscreen on-camera monitor with 2300 cd/m² brightness
• Slim, lightweight design with 10-bit 4:2:2 DCI-P3 color, touchscreen LCD panel
• HDMI and 6G-SDI inputs and outputs
• Tactile buttons around the monitor allow you to use the monitor in any condition
• The PageOS 5 toolset with EL Zone Exposure Assist, best-in-class waveform, false color, Look-Around Camera Control (sold separately), advanced Teradek RT overlays, and more
• Four 1/4"-20 mounting threads on the left, right, bottom, and back of the monitor
• Power using a 2-pin power input
• Optional RED camera control via the 5-pin USB port
• Optional ARRI/Sony VENICE camera control via the Ethernet port
• Durable aluminum chassis
