SmallHD 703 Bolt 7" Wireless Monitor
Combining a wireless video receiver and high-quality HD monitor, the SmallHD 703 Bolt 7" Wireless Monitor is an all-in-one director's monitor solution. Borrowing the wireless technology from Teradek, the 703 Bolt can receive uncompressed HD wireless signals from Bolt 500, 1000, or 3000 transmitters up to 300' away.
- (1) SmallHD 703 Bolt SDI 7" Wireless Monitor
- (1) Anton Bauer Gold Mount Battery Plate
- (1) 703 Bolt Antenna Bracket With (2) Screws
- (1) SmallHD 8GB Memory Card
- (2) Handle
- (1) Neck Strap
- (3) Small Antenna
- (1) 1.5' - D-Tap To 2-Pin Lemo Cable
- (1) 2' - SDI Cable
- (1) Baby to 1/4" 20 Male Threaded Adapter
- (1) Hard Case
$200.00 Day/Weekend Rate
$600.00 Week Rate
$1,800.00 Month Rate
- Panel Type:
IPS-Type LCD
- Display Size:
7.0"
- Screen Resolution:
1920 x 1080
- Aspect Ratio:
16:9
- Viewing Angle:
Horizontal: 160°
- Maximum Brightness:
3000 cd/m2
- Contrast Ratio:
1150:1
- Bit Depth / Color Support:
8-Bit (16.7 Million Colors)
- Pixels Per Inch (ppi):
323 ppi
- Color Gamut:
70% NTSC
- Image Controls:
Blue Only, False Color, Focus Peaking, Image Flip, Pixel-to-Pixel Zoom, RGB Parade, Screen Markers, Waveform
- Video:
1 x BNC (3G-SDI) Input/Output
1 x HDMI Type A Output
1 x BNC (3G-SDI) Input
- Embedded Audio:
SDI
Wireless
- Audio:
1 x 3.5 mm Headphone Output
- Built-In Speaker:
None
- Power:
1 x 2-Pin LEMO Input
- Other I/O:
1 x Wireless Receiver
- Card Slot:
1 x SD
- Video Format:
SDI (10-Bit 4:2:2 YCC)
1080p: 23.98/24/25/29.97/30/50/59.94/60
1080PsF: 23.98/24/25/29.97/30
1080i: 50/59.94/60
720p: 23.98/24/25/29.97/30/50/59.94/60
576i
480i
Wireless (10-Bit 4:2:2)
1080p: 23.98/24/25/29.97/30/50/59.94/60
1080PsF: 23.98/24/25/29.97/30
1080i: 50/59.94/60
720p: 50/59.94/60
576i
480i
- DC Input Power:
6 to 34 VDC
- Battery Type:
Gold Mount Plate
- Power Consumption:
16 W
- Certifications:
CE, FCC, RoHS, as per Manufacturer
- Operating Temperature:
0 to 100°F
- Storage Temperature:
-4 to 120°F
- Mounting:
4 x 1/4"-20 Female
- Weight:
2.8lbs
