SmallHD 703 Ultra Bright SDI & HDMI 7" Monitor

$150.00  / Day
Quantity
- +

  • (1) SmallHD 703 Ultra Bright SDI & HDMI 7" Monitor
  • (1) Anton Bauer Gold Mount Battery Plate
  • (1) 2' - Thin SDI Cable
  • (1) 3' - Thin HDMI Cable
  • (1) 3' - D-Tap To 2-Pin Lemo Cable
  • (1) SmallHD 8GB Memory Card
  • (1) Baby to 1/4" 20 Male Threaded Adapter (Stand Adapter)
  • (1) Hard Case

$150.00 Day/Weekend Rate
$450.00 Week Rate
$1,350.00 Month Rate

Display

  • Panel Type:

TFT LCD

  • Display Size:

7.0"

  • Screen Resolution:

1920 x 1080

  • Aspect Ratio:

16:9

  • Viewing Angle:

Horizontal: 178° (89/89)
Vertical: 178° (89/89)

  • Maximum Brightness:

2200 cd/m2

  • Contrast Ratio:

1200:1

  • Bit Depth / Color Support:

10-Bit (1.07 Billion Colors)

  • Pixels Per Inch (ppi):

323 ppi

  • Color Gamut:

70% NTSC

  • Image Controls:

Blue Only, False Color, Focus Peaking, Image Flip, Pixel-to-Pixel Zoom, RGB Parade, Screen Markers, Waveform



I/O

  • Video:

1 x BNC (3G-SDI) Output
1 x HDMI Type A Output
1 x BNC (3G-SDI) Input
1 x HDMI Type A Input

  • Embedded Audio:

HDMI
SDI

  • Audio:

1 x 3.5 mm Headphone Output

  • Built-In Speaker:

None

  • Power:

1 x 2-Pin LEMO Input
1 x 2-Pin LEMO Output

  • Card Slot:

1 x SD



Format Support

  • Video Format:

SDI (10-Bit 4:2:2)
1080p: 23.98/24/25/29.97/30/50/59.94/60
1080PsF: 23.98/24/25/29.97/30
1080i: 50/59.94/60
720p: 23.98/24/25/29.97/30/50/59.94/60
480i
576i
HDMI (8/10/12-Bit)
1080p: 23.98/24/25/30/50/59.94/60
1080PsF: 23.98/24/25/30
1080i: 50/59.94/60
720p: 23.98/24/25/30/50/59.94/60/100/119.88/120
576p: 50/100
480p: 59.94/60/119.88/120
480i: 59.94/60/119.88/120/239.76/240
576i: 50/100/200



Power

  • DC Input Power:

6 to 34 VDC

  • Battery Type:

None

  • Power Consumption:

13 W



Environmental

  • Certifications:

CE, FCC, IC, RoHS, as per Manufacturer

  • Operating Temperature:

0 to 100°F

  • Storage Temperature:

-4 to 120°F



General

  • Mounting:

2 x 1/4"-20 Female

  • Dimensions:

4.9”x8.4”x1.1"

  • Weight:

1.7 lbs
