Teradek Bolt 1000 Wireless Monitor 1:1 Kit
- (1) Teradek Bolt 1000 Transmitter
- (1) Teradek Bolt 1000 Receiver
- (5) Teradek Small Antenna
- (2) Teradek Large Antenna
- (2) SmallRig Universal Magic Arm
- (3) 2’ – SDI Cable
- (3) 3' - HDMI Cable
- (3) 1.5’ D-Tap To 2-Pin Lemo Cable
- (1) Teradek AC Power Supply
- (1) Hard Case
$975.00 Week Rate
$2,925.00 Month Rate
- Construction:
Milled aluminum (chassis) and regulation-compliant PCB
- Video Inputs:
3G/HD/SD-SDI: 1 x BNC (75 Ohms) (Available in HDMI)
- Video Outputs:
3G/HD/SD-SDI: 1 x BNC (75 Ohms, loop-through out) (Available in HDMI)
- Color Sampling:
YCbCr 4:2:2, 10-bit (8-bit when format conversion is enabled)
- Latency:
<0.001 seconds (TX to RX without format conversion)
- Supported Resolutions:
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080PsF: 30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
480i: 59.94
576i: 50
- Video Processing:
Compression
Visually lossless
Color Correction
CDL/1024 1D LUT (supports 10-bit color)
33x33x33 3D LUT (supports 10-bit color)
- Audio Compression:
48 kHz, 24-bit PCM
- Audio Input:
Embedded
- Interfaces:
Switches: On/Off and Reset
Desktop App: Feature-rich Bolt Manager application for OS X and Windows
USB Interface Functionality: Upgrade via mini-USB
- Wireless:
Non-DFS Frequencies
UA: 5.19 to 5.23 GHz, 5.755 to 5.795 GHz
EU & JP: 5.19 to 5.23 GHz
DFS Frequencies
US: 5.27 to 5.55 GHz and 5.67 GHz
EU & JP: 5.27 to 5.67 GHz
- RF Power:
17 dBm EIRP
- Encryption:
AES-128
- Range:
Up to 1000'
- Unicast Multicast:
Unicast / Multicast
- Noise Rejection:
Can coexist with Wi-Fi and 5 GHz cordless phones
- Power Input:
2-pin connector
7 to 17 VDC
- Power Consumption:
Nominal 7.3 W (measured at 1080p60)
- Operating Temperature:
32 to 104°F
- Mountable:
Multiple mounting options with M3 and 1/4" holes
3/8" ARRI style accessory mount
- Dimensions:
0.95” x 2.6” x 4.47"
- Weight:
8 oz
