$450.00 Day/Weekend Rate
$1,350.00 Week Rate
$4,050.00 Month Rate

We offer a price match guarantee—if you find a lower advertised rate for the same equipment from another Chicago rental house, we'll match it, no questions asked.

For custom rental periods or special requirements, contact our team at rentals@cameraambassador.com to discuss tailored pricing.

Sensor:

Super35mm CMOS

System:

RGB primary color filter (Bayer array)

Total Pixels Per Sensor:

9.84 megapixels

Effective Pixels Per Sensor:

Approx. 8.85 megapixels when 4096 x 2160 / 2048 x 1080 resolution selected

Effective Pixels Per Sensor:

Approx.8.29 megapixels when 3840 x 2160 or 1920 x 1080 resolution selected

Minimum Illumination:

59.94 Hz Mode** Lux [F1.2 lens, 24 dB, PF59.94 mode, shutter speed 1/**]

50 Hz Mode** Lux [F1.2 lens, 54 dB, PF50, shutter speed 1/**]

Sensitivity:

59.94 Hz Mode F*[1920 x 1080 / 59.94i, ISO*** (*dB), 2000 Lux, 89.9 % reflection]

50 Hz Mode: F** [1920 x 1080 / 50.00i, ISO*** (*dB), 2000 Lux, 89.9 % reflection]

S/N Ratio:

59.94 Hz Mode **dB (Typical) [4096 x 2160 / PF29.97, Canon Log base sensitivity ISO 850 (Dynamic range 800 %)]

5 0Hz Mode: 54 dB (Typical) [1920 x 1080 / PF25, Canon Log base sensitivity ISO 850 (Dynamic range 800 %)]

Dynamic Range:

With Canon Log gamma: 800 %, With Canon Log2 Gamma 1600 % (ISO 850 or above / gain 2.5 dB or more)

Horizontal Resolution:

Up to 1800 TV lines or more depends on shooting resolution and on lens used.

Lens Mount:

Canon EF Mount

Focal Length Adjustment:

3840 x 2160 or 1920 x 1080 resolution: Actual focal length x approx. 1.53

Focal Length Adjustment:

4096 x 2160 or 2048 x 1080 resolution: Actual focal length x approx. 1.46

As Indicated For EF-S Lenses and Canon Cine Zoom Lenses

Peripheral Illumination Correction:

Yes, dependent on lens used

ND Filter:

6 glass filters in camera body: 2 stops; 4 stops; 6 stops,8 stops,10 stops. Operate via body

Focus Control:

Via lens, wireless control or wired remote (dependent on lens used) One shot AF with EF Lenses Including Cine Servo Lens Range². (Not Available with Manual Focus, CINEMA Zoom or Prime Lenses).

Iris Control:

Via body, grip, wireless control or wired remote. Push AI available with EF lens (Not available with

CINEMA Lenses) 1/2-Stop, 1/3-Stop or FINE Control. Possible to Maintain Constant F- Number During Zoom.

Image Stabilization System:

Depends on lens used

Image Processor Type:

Dual DIGIC DV5

Video Storage Media:

CFast2.0 and SD card supported. Simultaneous Recording to

Cfast2.0 And External Device Possible

Recording File Format:

XF-AVC (Material eXchange Format (MXF))

Recording Standard:

Video Compression: MPEG-4 AVC/H.264

Audio Recording:

Linear PCM (16bit/24bit-48k Hz -4ch)

File Format:

XF-AVC (MXF)

Bit Rate:

Intra 410 / 225/220 / 110Mbps, LongGOP50Mbps

Long GOP:

35 or 24 Mbps (for proxy recording on SD cards)

Recording Format SD Card:

Movies:

Long GOP recording only (*)

Resolution:

2048 x 1080 / 1920 x 1080

Signal Configuration:

YCC420 8bit Photo: JPEG

Resolution:

2048 x 1080 / 1920 x 1080 (*) Proxy recording using low bit rate

Recording Frame Rate:

59.94 Hz:

59.94i / 59.94P / 29.97P / 23.98P (Depending on resolution selected)

50.00 Hz:

50.00i /50.00P / 25.00P (Depending on resolution selected)

24.Hz:

24.00P

Slow / Fast Motion:

59.94 Hz: 59.94p:

2K (2048 X 1080 / 1920 X 1080):

1 to 60 (1fps increments) / x60 to x1

2K CROP (*1)(2048 X 1080 / 1920 X 1080) & Intra:

1 -60 -120 / x60 -x0.5 (2 fps increments for rates over 60fps)

2K CROP (*1) (2048 X 1080 / 1920 X 1080) & Long GOP:

1 to 60 (1fps increments) / x60 to x1 (1fps increments)

97p:

4K (4096 X 2160 / 3840 X 2160) 1 -30 (1fps Increments):

/x30 -x1

2K (2048 X 1080 / 1920 X 1080) & RGB 1 -30 (1fps Increments):

/ x30 -x1

2K (2048 X 1080 / 1920 X 1080) & YCC 1 -30 -60 (1fps Increments):

/ x30 -x0.5

2K CROP (*1) (2048 X 1080 / 1920 X 1080) &Intra & YCC:

1 -30 -120 / x30 -x0.25 (2fps increments for rates over 60fps)

2K CROP (*1) (2048 X 1080 / 1920 X 1080) & Long GOP & YCC:

1 -30 -60 / x30 -x1/2 (1fps increments)

98p:

4K (4096 X 2160 / 3840 X 2160) 1 -24 -30 (1fps Increments):

/ x24 -x0.8

2K (2048 X 1080 / 1920 X 1080) &RGB 1 -24 -30 (1fps Increments):

/ x24 -x0.8

2K (2048 X 1080 / 1920 X 1080) &YCC 1 -24 -60 (1fps Increments):

/ x24 -x0.4

2K CROP (*1) (2048 X 1080 / 1920 X 1080) & Intra & YCC:

1 -24 -120 / x24 -x0.2 (2fps increments for rates over 60fps)

2K CROP (*1) (2048 X 1080 / 1920 X 1080) & Long GOP &YC:

1 -24 -60 / x24 -x0.4 (1fps increments)

00 Hz:

50.00p:

2K (2048 X 1080 / 1920 X 1080) 1 -50 (1fps Increments):

/ x50 -x1

2K CROP (*1) (2048 X 1080 / 1920 X 1080) & Intra:

1 -50 -120 / x50-x0.42 (2 fps increments for rates over 50fps)

2K CROP (*1) (2048 X 1080 / 1920 X 1080) & Long GOP:

1 -50 (1fps increments) / x50 -x1

00p:

4K (4096 X 2160 / 3840 X 2160) 1 -25 (1fps Increments):

/ x25 -x1

2K (2048 X 1080 / 1920 X 1080) & RGB 1 -25 (1fps Increments):

/x25 -x1

2K (2048 X 1080 / 1920 X 1080) & YCC 1 -25 –50(1fps Increments):

/ x25 -x0.5

2K CROP (*1) (2048 X 1080 / 1920 X 1080) & Intra & YCC:

1 -25 -120 / x25 -x0.21 (2fps increments for rates over 50fps)

2K CROP (*1) (2048 X 1080 / 1920 X 1080) & Long GOP& YCC:

1 -25 -50 / 250 -50 % (1fps increments)

00 Hz:

4K (4096 X 2160 / 3840 X 2160) 1 -24 -30 (1fps Increments):

/ x24 -x0.8

2K (2048 X 1080 / 1920 X 1080) & RGB 1 -24 -30 (1fps Increments):

/ x24 -x80

2K (2048 X 1080 / 1920 X 1080) & YCC 1 -24 -60 (1fps Increments):

/ x24 -x0.4

2K CROP (*1) (2048 X 1080 / 1920 X 1080) & Intra & YCC:

1 -24 -120 / x24 -x0.2 (2fps increments for rates over 60fps)

2K CROP (*1) (2048 X 1080 / 1920 X 1080) & Long GOP& YCC:

1 -24 -60 (1fps increments) / x24 -x0.4 (*1)

 The 2K area

Interval Record:

Yes

Frame Record:

Yes

Pre Record (Cache Record):

Yes

Relay Recording:

Yes

Double Slot (Simultaneous) Recording:

Yes

Scan Reverse:

Yes: Both / Vertical/ Horizontal /Off

HD->SD Conversion:

No

Internal Data Transfer:

Yes

Photo Storage Media:

SD Card

Still Quality:

2048 x 1080 / 1920 x 1080

LCD Size:

4” (10.1 cm diagonal) color wide-screen LCD with 16:9 aspect ratio

LCD Dots:

Approx. 1.23 million dots (854 x RGB x 480), 100 % field of view coverage

LCD Image Quality Adjustments:

Super High, High or Normal can be selected as the luminance adjustment. Others are same as for the viewfinder.

LCD Adjustable:

Yes

LCD Waveform Monitor:

Yes

LCD Focus Assist:

Yes

LCD Peaking:

Yes

LCD Zebra:

Yes

LCD Markers:

Yes

EVF Size:

0.46” (1.18 cm on the diagonal), color organic EL display with a wide-screen 16:9 aspect ratio

EVF Type:

Organic LED

EVF Dots:

Approx. 1770,000 dots (1024 x RGB x 576)

EVF Image Quality Adjustments:

Adjustment of the viewfinder brightness, contrast, color, sharpness and luminance

Boosting (On/Off) Can Be Performed (Using Menu Settings).

EVF Adjustable:

Yes

EVF Correction Lens:

+2.0 to -5.5 diopter

Audio In:

2x XLR input on monitor unit, 3.5 mm input on Camera Body

Headphone Output:

Output impedance 50Ω or less, Reference signal output level 50Ω or less

Reference Signal Output Level:

-∞ to -12 dBV(with 16Ω load, volume from MIN to MAX)

Video/Audio Output:

MON., REC OUT terminals: BNC Jack

Video [HD]:

SMPTE 292, SMPTE 274 [3G]: SMPTE 424, SMPTE 425

Audio [HD]:

SMPTE ST 299-1 [3G]: SMPTE ST 299-2 Output impedance 75Ω, Output signal level 0.8Vp-p

HDMI:

HDMI terminal (type A) Complies with HDMI specifications. Video / Audio output

Firewire:

No

USB:

No

Time Code:

BNC jack (input / output)

Genlock:

BNC jack (also serves as the SYNC OUT terminal) Signal level 1.0 Vp-p, Input impedance 10KΩ

Synch:

BNC jack (also serves as the SYNC OUT terminal) Signal level 1.0 Vp-p, Input impedance 10KΩ

LCD Monitor Input/Output:

VIDEO terminal Canon’s proprietary specifications (special 13-pin jack)

LCD Monitor Input/Output:

AUDIO terminal Canon’s proprietary specifications (special 13-pin jack)

Component Out:

No

AV Terminal:

No

DC Input:

Yes

Remote Control Terminal:

2.5 mm mini jack

Color Bars:

EBU, SMPTE, ARIB

Tally Lamp:

Yes

Accessory Shoe:

Cold shoe, 3 locations: top of body, top of handle, front of handle)

Exposure Control & Metering:

Manual, Push Auto Iris, Auto Iris (with compatible lenses).

Metering Options:

Standard (center-weighted metering), Spotlight & Backlight compensation

Exposure Compensation:

0.25 increments from ±0 to ±2.0.

Push Auto Iris:

Yes (EF and EF-S lenses. Not available with EF Cinema Lenses.)

Exposure Lock:

Via Push AI Function

Auto Gain Control Setting:

Yes

Iso Sensitivity:

1 Stop Increments:

[100], 160(*), 200, 400, 800, 1600, 3200, 6400, 12800, 25600, [51200, 102400] [---]

Displayed When ISO Speed Expansion Is ON. (*) Displayed When ISO Speed Expansion Is OFF.

1/3 Stop Increments:

[100, 125], 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2500,

3200, 4000, 5000, 6400, 8000, 10000, 12800, 16000, 20000, 25600,

[32000, 40000, 51200, 64000, 80000, 102400]

Gain Setting:

Normal:

[-6dB, -3dB], -2dB (*), 0dB, 3dB, 6dB, 9dB, 12dB, 15dB, 18dB, 21dB, 24dB, 27dB,30dB,

33db, 36db, 39db, 42db, [45db, 48db, 51db 54db] [---] Displayed When ISO Speed Expansion Is ON. (*)

Displayed When ISO Speed Expansion Is OFF.

Fine:

Any value from -2dB to 24dB in 0.5dB increments can be set.

Shutter Speed Control Modes:

Off, Speed, Angle, Clear Scan, Slow

Shutter Speed 59.94 Hz:

Off:

59.94(i/P): 1/60/29.98P: 1/30 24.00P 1/24

Speed:

1/1 -1/2000

Clear Scan:

59.94 Hz mode: 23.98 Hz (lowest) to 250.37 Hz 24.00 Hz mode: 24.00 Hz (lowest) to 250.37 Hz (frequency will differ depending on the frame rate setting)

Slow:

59.94(i/P) 1/4, 1/8, 1/15, 1/30; 29.98P 1/4, 1/8, 1/15: 24.00P 1/3, 1/6, 1/12

Shutter Speed50.00 Hz:

Off:

50.00(i/P) 1/50; 25.00P 1/25

Speed:

1/1 -1/2000

Clear Scan:

24.00 Hz (lowest) to 250.40 Hz Note: The frequency will differ depending on the frame rate setting.

Slow:

50.00(i/P) 1/3, 1/6, 1/12, 1/25; 25.00P 1/3, 1/6, 1/12

Shutter Angle 59.94 Hz / 50.00 Hz:

360.00, 240.00, 180.00, 120.00, 90.00, 60.00, 45.00, 30.00, 22.50, 15.00, 11.25

AF Options:

Dependent on the interchangeable lens used and User Selected Mode. Dual Pixel CMOS AF (CMOS AF), Contrast AF

AF Modes:

One-Shot AF, Continuous AF and AF-Boosted MF are the available modes. All of these modes take

Effect When The AF/MF Switch of The EF Lens Is at The AF Setting

Face Detection AF:

Face Priority or Face Only

Dual Pixel CMOS AF:

Compatible with all EF Mount Lenses (Except Manual Focus Only Models)

Audio Recording:

16-bit 2ch (48 kHz) linear PCM

Audio Control:

Independent limiters and auto / manual settings

Microphone Attenuation:

Yes

Microphone Level Meter:

Yes

Battery Type:

BP-A30/BP-A60

Input Power Supply:

14.4 V DC (battery pack), 16.7 V DC (DC IN)

Operating Temperature Range:

32°F to 104°F, 85 % (relative humidity)

41°F to 113°F, 60 % (relative humidity)

Dimensions:

5.9”x”7.2x7.2" (Body Only)

Weight:

3.9 lbs +/- (Body Only)
